100W E40 E39 E27 E26 Base LED Retrofit Kit Lights for Shoebox, Wall pack, Cobra head Street fixtures
  • 100W E40 E39 E27 E26 Base LED Retrofit Kit Lights for Shoebox, Wall pack, Cobra head Street fixtures
  • 100W E40 E39 E27 E26 Base LED Retrofit Kit Lights for Shoebox, Wall pack, Cobra head Street fixtures
  • 100W E40 E39 E27 E26 Base LED Retrofit Kit Lights for Shoebox, Wall pack, Cobra head Street fixtures
  • 100W E40 E39 E27 E26 Base LED Retrofit Kit Lights for Shoebox, Wall pack, Cobra head Street fixtures
  • 100W E40 E39 E27 E26 Base LED Retrofit Kit Lights for Shoebox, Wall pack, Cobra head Street fixtures
  • 100W E40 E39 E27 E26 Base LED Retrofit Kit Lights for Shoebox, Wall pack, Cobra head Street fixtures
100W E40 E39 E27 E26 Base LED Retrofit Kit Lights for Shoebox, Wall pack, Cobra head Street fixtures100W E40 E39 E27 E26 Base LED Retrofit Kit Lights for Shoebox, Wall pack, Cobra head Street fixtures100W E40 E39 E27 E26 Base LED Retrofit Kit Lights for Shoebox, Wall pack, Cobra head Street fixtures100W E40 E39 E27 E26 Base LED Retrofit Kit Lights for Shoebox, Wall pack, Cobra head Street fixtures100W E40 E39 E27 E26 Base LED Retrofit Kit Lights for Shoebox, Wall pack, Cobra head Street fixtures100W E40 E39 E27 E26 Base LED Retrofit Kit Lights for Shoebox, Wall pack, Cobra head Street fixtures

100W E40 E39 E27 E26 Base LED Retrofit Kit Lights for Shoebox, Wall pack, Cobra head Street fixtures

1. Light Source: Philips 3030

2. Luminous Flux: 14,400 Lumen

3. Rated Wattage: 100Watt

4. Base: E40/E39(mogul) E27/E26(Medium)

5. Input Voltage: 100-277VAC, 180-480VAC

6. Beam Angle: 120 degree

7. IP Rating: IP65

8. Lifetime: 50,000+ hours

9. Arm rotatable and length adjustable

10. 350W HID/Metal Halide Equivalent.

11. ETL cETL DLC CE RoHS listed.

Inquire Now Next Product

100W E40 E39 E27 E26 Base LED Retrofit Kit Lights for Shoebox, Wall pack, Cobra head Street fixtures

Name:

Tel:

E-mail:

Country:

CAPTCHA:

Submit the information to obtain product spec sheet,Please make sure that your email address is absolutely correct!

Specification Sheet
  • Data Sheets
  • Beam Angle
  • Options/Accessories
  • Package details

Overview


100W LED Retrofit Kit Lights

100W LED retrofit kit, 144LM/W high efficiency, ETL cETL DLC CE RoHS certified. Rotatable angle and E40 E39 E27 E26 base allows the retrofit kit to adapt to a wide range of luminaires. Widely used in replacing HID, MH bulbs in Shoebox, Wall pack, Canopy, High Bay, Cobra head Street fixtures.

commercial outdoor parking lot lights adn wall pack led retrofit


Size

led retrofit kits dimension  DLC led retrofit kits 30w 150w

Specifications

ModelLSRK-100WXY
Wattage100W
Lumens14400(144LM/W)
Light SourcePhilips SMD 3030
LED QTY160pcs
Driver PowerMeanwell Driver HLG-80H-48A
DimensionE27/E26 : Dia145*230mm / 9.05''   (Shortest size)E27/E26 : Dia145*300mm  / 11.8''  (Longest size)E40/E39 : Dia145*234mm / 9.84''   (Shortest size)E40/E39 : Dia145*288mm / 12.59'' (Longest size)
CCT3000K/4000-4500K/5000-5700K/6000-6500K
Input Voltage100-300VAC,50/60Hz
Power Factor>0.95
Cap TypeE40 E39 (mogul)  , E26  E27 (Medium)
ConstructionAluminum fin heat sink bulit-in+ Sunon Fan
Beam Angle120 degrees
IP RatingIP60
CRI>80
Warranty5 year Warranty
Rated Lifespan50,000+hours
Equivalent350W metal halide / HID lamp Equivalent
CertificationsETL cETL TUV CE RoHS SAA FCC DLC Ctick certified


Main Feature

  • 5 years warranty.

  • 0-10V Dimmable Optional.

  • Various beam angle of 120 degree.

  • Original Philips SMD 3030 LEDs which is up to 133Lm/W.

  • Arm adjustable with any beam angle.

  • With a big Sunon fan(60,000hours).

  • Body Temperature:<55 oC  @Ta=25 oC

  • With the most excellent quality meanwell driver.

  • Available with both 100-300VAC & 347VAC & 480VAC.

  • Using aluminum fin heat sink which heat transfer faster than die cast.

  • Tiny package and lighter,lower freight cost,more competitive in the market.

  • Avaialble for low bay fixture,street pole,canopy,parking lot shoebox,wall pack,high bay fixtures etc.

  • ETL cETL TUV CE RoHS SAA FCC DLC Ctick certified


Main Construction Features

1.Sunon fan; 2.Hexagon heat sink; 3.E40 to E27; 4. Aluminum heat sink; 5.Philips SMD 3030;


led retrofit kit Main Construction Features


DETAIL DESCRIPTION

1.Using aluminum fin heat sink which heat transfer faster than die cast.Tiny packageand lighter,lower freight cost,morecompetitive in the market. Lamp :0.8kg;

2.Using AL1050 aluminum fin heat sink.Can be used in a sealed environment.Thermostatthermal protector;

3.Module Rotatable 360 degree;


light weight 100w led retrofit kits

100w led retrofit kits cooling

led retrofit lamp fixture solution  e40 led retrofit lamp fixture solution

Applications

  • LED Retrofit Kits For Wall Packs

  • LED Retrofit Kit For High Bay Lights

  • Parking Garage Lighting

  • High-Bay Lighting

  • Warehouse Lighting

  • Low Bay Lighting


LED Retrofit Kit for MH Fixtures,LED Retrofit Kit for HID Fixtures

100w led retrofit kits rotatable 360 degree

led retrofit kits Accessories

Packaging

led retrofit kits package


  length width heightGW(kg)
Inner Box (1pc)  32cm  29cm 16cm1.5
Outer Carton (4pcs)  63cm   61cm 33cm11.6
