45W LED Retrofit Kits for 125W Metal Halide Fixtures 6,480Lm Parking Lot Lighting Retrofit

1. Light Source: Philips 3030
2. Luminous Flux: 6,480 Lumen
3. Rated Wattage: 45Watt
4. Base: E40/E39(mogul) E27/E26(Medium)
5. Input Voltage: 100-277VAC,180-500VAC
6. Beam Angle: 120 degree
7. IP Rating: IP65
8. Lifetime: 50,000+ hours
9. Arm rotatable and length adjustable
10. 75W-105W HID/Metal Halide Equivalent.
11. ETL cETL DLC CE RoHS listed.

  • Data Sheets
  • Features/Benefits
  • Options/Accessories
  • Lighing Layout

45w led retrofit kits.jpg

DLC Numbers

XY stands for color temperature, XY = 30,40,45,50,57 (30 equals to 3000K,40 equals to 4000K ...) when you seach on QPL,please put LSRK-60W30 LSRK-60W40, the rest can be searched in the same manner.


Main Feature

  • 5 years warranty.

  • 0-10V Dimmable Optional.

  • Various beam angle of 120 degree.

  • Original Philips SMD 3030 LEDs which is up to 133Lm/W.

  • Arm adjustable with any beam angle.

  • With a big Sunon fan(60,000hours).

  • Body Temperature:<55 oC  @Ta=25 oC

  • With the most excellent quality meanwell driver.

  • Available with both 100-300VAC & 347VAC & 480VAC.

  • Using aluminum fin heat sink which heat transfer faster than die cast.

  • Tiny package and lighter,lower freight cost,more competitive in the market.

  • Avaialble for low bay fixture,street pole,canopy,parking lot shoebox,wall pack,high bay fixtures etc.

  • ETL cETL TUV CE RoHS SAA FCC DLC Ctick certified


Outer Dimension

45w led retrofit kits dimension    DLC led retrofit kits 30w-150w.jpg

Specifications - 45W LED Retrofit Kits

ModelLSRK-45WXY
Wattage45W
Luminous Flux6,480Lm
Light SourcePhilips SMD 3030
LED QTY72pcs
Driver PowerExternal Meanwell Driver PLN-30-24A
Dimension E27/E26 : Dia145*230mm / 9.05''   (Shortest size)
E27/E26 : Dia145*300mm  / 11.8''  (Longest size)
E40/E39 : Dia145*234mm / 9.84''   (Shortest size)
E40/E39 : Dia145*288mm / 12.59'' (Longest size)
Equivalent 75W  to 105W metal halide / HID lamp Equivalent
CCT3000K/4000-4500K/5000-5700K/6000-6500K
Input Voltage100-300VAC,50/60Hz
Power Factor>0.95
Cap TypeE40 E39 (mogul)  , E26  E27 (Medium)
optical lensN/A
ConstructionAluminum fin heat sink bulit-in+ Sunon Fan
Beam Angle120 degrees
IP RatingIP60
CRI>80
Working Tempe / Humidity-45 to + 50 Deg C / @Ta=25 Deg C
Warranty5 year Warranty
Rated Lifespan50,000+ hours
CertifiedETL cETL TUV CE RoHS SAA FCC DLC Ctick certified

Applications

  • LED Retrofit Kits For Wall Packs

  • LED Retrofit Kit For High Bay Lights

  • Parking Garage Lighting

  • High-Bay Lighting

  • Warehouse Lighting

  • Low Bay Lighting

Main Construction Features

Main Construction Features

DETAIL DESCRIPTION

low weight 30w led retrofit kitsled retrofit kitsled retrofit kits Cooling.jpgled retrofit kits rotating degree.jpg


Retrofitting

led retrofit lamp fixture solution.jpge40 led retrofit lamp fixture solution.jpg

Applications

LED Retrofi t Kit for MH Fixtures,LED Retrofi t Kit for HID Fixtures

led retrofit kits Accessories

Packaging

led retrofit kits Package


  length width heightGW(kg)
Inner Box (1pc)  32cm  29cm 16cm1.5
Outer Carton (4pcs)  63cm   61cm 33cm11.6
