720W LED Sports Lighting, 100-277VAC, 170Lm/W, 1500W Equivalent, 122400 Lumens

●   Watt: 720W

●   Lumens: 115,200/ 122,400

●   Light Source: Lumileds 5050

●   Input Volt: 100-277VAC

●   IP Rating: IP66 - IK10

●   Size: 649*375*188mm

●   Lamp Weight: 12.5kg

●   CCT (Color Temp): 3000, 4000, 5000, 6000

●   5 years warranty

●   Beam Angle: 10/20/40/60/90/140*100/135*60(P50)

Inquire Now Next Product

720W LED Sports Lighting, 100-277VAC, 170Lm/W, 1500W Equivalent, 122400 Lumens

Name:

Tel:

E-mail:

Country:

CAPTCHA:

Submit the information to obtain product spec sheet,Please make sure that your email address is absolutely correct!

Specification Sheet
  • Data Sheets
  • Beam Angle
  • Options/Accessories
  • Package details

Specifications

Model No.LSHM‐B720W‐LV(XXK)
Watt
720W
Lumen115,200
122,400
Efficiency160Lm/W±3%170Lm/W±3%
Input Volt100-277VAC
Chip BrandLumileds/ Osram 5050
CCT3000K 4000K 5000K 5700K 6500K4000K, 5000K
ModulesNone Rotatable
Weight12.5kg
Size649*375*188mm
Beam Angle10/ 20/ 40/ 60/ 90 degree/ 140*100/ 135*60 degree(P50)
DriverMeanwell 3pcs XLG-240-H-A/ ELG-240-48A
Wind rating51.0-56.0m/s
IP RatingIP66 & IK10
CRIRa70 (Ra80, Ra90 optional)
DimmableOptional dimmable and non-dimmable
CertificationENEC REACH ETL DLC TUV CE CB SAA RoHS LM79 LM80 TM21 Salt Spray test approved
Life TimeL70/B10 >50,000hours
Warranty5 Years / 7 years extended warranty available


720W Module LED Flood Lights

Slim Pro 720W LED Sports Lighting

ENEC REACH ETL DLC TUV CE CB SAA RoHS LM79 LM80 TM21 Salt Spray test approved certified icon


  • 175Lm/W can save a lot of energy consumption for your stadium sports field and get more and higher quality light;

  • 720 watt Module LED Flood light can emit 122,400 lumens of light and can replace 1500 watt metal halide MH or HPS / HID lamps. 3000-6500K optional light colors ensure that bright and clear light with different color temperatures can be selected in different scenes;

  • Using folding Aluminum Fin design, light weight, Thermal effect is good;

  • The bracket can be rotated up and down for easy adjustment, and can be installed in various ways. Ideal for directing light more precisely in the right direction or areas with special lighting requirements. It is the best installation or refurbishment option for basketball courts, football fields, baseball fields, golf courses and other sports fields;


Size

Slim Pro 720W LED Sports Lighting Dimensioning

Why Choose 720W LED Sports Lighitng

Slim Pro led sports lighting

1.High luminaire efficiency up to 175lm/w

2.Marine grade aluminum housing

3.IP66 and IK10 protection rate

4.5 years warranty

5.Folding aluminum fin design which are very light weight

6.ENEC ETL DLC TUV CE CB SAA RoHS LM79 LM80 TM21 IK10 Salt Spray test approved

7.Module Rotatable ±25° ,Separate module can be mounted on the same robust bracket to offer the utmost flexibility.

Module Adjustment Installation


1.High Quality LED Brand

Uses Lumileds 5050, High Efficiency 160-170Lm/W.

Slim Pro 720W LED Sports Lighting uses lumileds 5050


2.Folding aluminum fin design

Lightweight, fast heat dissipation. Increase the heat dissipation surface area by air coolingto dissipate heat and expand the contact area with air! It speeds up the spread of heat! Thermal effect is good.

Slim Pro 720W LED Sports Lighting Folding aluminum fin design


3.Protection class

1.IP66 & Lightning protection & IK10. Waterproof IP66 and lightning protection 10/20KV, IK10 protective design allows Slim PRO LED High MAST LIGHT to withstand harsh environments;

Slim Pro 720W LED Sports Lighting IP66 & IK10 Protection class


Photometrics

The optical lens is made of PC, and the transmittance reaches 92%,reducing light loss,maximize the lumens on where it should be lit up and evenness, minimize lighting pollution to nature and human life.

10/20/40/60/90 degree/140*100/135*60 degree(P50)


Certification Testing


Installation

1.Wall installation 2. Ground installation 3.Pole installation


Slim Pro LED sports Light installation method


Application

LED Flood Light is very suitable for large areas such as sports fields, stadiums, Racing track, Ballpark airports, terminals, etc.

application

Beam angle

The optical lens is made of PC, and the transmittance reaches 92%,reducing light loss,maximize the lumens on where it should be lit up and evenness, minimize lighting pollution to nature and human life.

10/20/40/60/90 degree/140*100/135*60 degree(P50)

Accessories

347-480VAC Sosen driver

1-10V Dimmable
10KV or 20KV SPD
Slip fitterSlip fitter
Round Installation plateRound Installation plate
Anti glared visorAnti glared visor
Laser pointerLaser pointer
Remote driver boxRemote driver box


Package details

Wattage720W
Size of box(cm)
66*60*26
Weight16kg
