400W LED Stadium Flood Light with Bracket Mounting , 72,000lm 100-277V Super Bright Sport Light Fixtures

●   Watt: 400W

●   Lumens: 72,000

●   Light Source: Lumileds 5050

●   Input Volt: 100-277VAC

●   IP Rating: IP66 - IK08

●   Size: 531*377*129mm

●   Lamp Weight: 15kg

●   Optional Colors: Silver Gray, Black

●   CCT (Color Temp): 4000, 5000

●   5 years warranty

●   Beam Angle: 15/ 30/ 60/ 90 degree/ TPII/ TPIII

Inquire Now Next Product

400W LED Stadium Flood Light with Bracket Mounting , 72,000lm 100-277V Super Bright Sport Light Fixtures

Name:

Tel:

E-mail:

Country:

CAPTCHA:

Submit the information to obtain product spec sheet,Please make sure that your email address is absolutely correct!

Specification Sheet
Model

LSHM‐400W‐LV(XXK)Ultra

Watt400W
Lumen72,000
Efficiency180Lm/W±3%
Driver

Meanwell Driver 2*ELG-240-48A

Input Volt100-277VAC
Chip Brand

Lumileds 5050

CCT4000K, 5000K
Weight15kg
Size
531*377*129mm
Color Rendering IndexRa70 (Ra80, Ra90 optional)
Power Factor>0.95
IP&IK RatingIP66 / IK10
Life TimeL70/B10 >50,000hours
Warranty5 Years / 7 years extended warranty available
DimmableDimmable and Non-dimmable
Beam Angle15/ 30/ 60/ 90 degree/ TPII(137*80 degree)/ TPIII(146*83 degree)
CertificationTUV, CE, CB, SAA, RoHS, LM79, LM80, TM21, IK10, Salt Spray test approved

Ultra LED Stadium Flood Light 400W

Ultra LED Stadium Flood Light 400W

Ultra LED Stadium Flood Light is a perfect Outdoor lighting solution for area, stadium.

400W

Lumileds 5050

180Lm/W

3000K-6000K

TUV CE CB SAA RoHS

LM79 LM80 TM21 IK10 Salt Spray test approved

High quility LED Brand

High quility LED Brand

Uses Lumileds 5050, High Efficiency 180Lm/W.

Lumileds 5050

Honeycomb heat dissipation design

Honeycomb heat dissipation design

ADC12 aluminum alloy integrated die-casting, honeycomb heat dissipation design, heat dissipation effect is more.

Honeycomb heat dissipation design

Rotatable Bracket

Rotatable Bracket

Rotating scale on the luminaire for customers to adjust the angle more accurately.

Rotatable

Other Watt

Ultra LED Sports Light is available in wattage from 400W to 1800W, which is the best choice to replace the existing MH/HID street lights of 1000W-3500W.

Ultra led sports light

Ultra led sports light

Ultra led sports light

Beam angle

Beam angle

The beam angle can be selected from 15/ 30/ 60/ 90 degree/ TPII(137*80 degree)/ TPIII(146*83 degree). Professional light distribution angle can better achieve uniform and efficient lighting effect.

15/ 30/ 60/ 90 degree/ TPII(137*80 degree)/ TPIII(146*83 degree)

Application

Tennis courts, basketball courts, football fields, large squares, areas, etc.

stadium light application

stadium light application

stadium light application

Accessories

1-10V Dimmable

10KV SPD

Anti-glare CoverAnti-glare Cover


Anti-glare Cover

Optional anti-glare cover

Ultra led stadium flood light with and without anti-glare cover

WattSize
400W 1pc/ 531*377*129mm


400W ultra LED Stadium Flood Light size
