300W LED Billboard Light, Adjustable Mounting Bracket Outdoor Sign LED Lighting Fixtures
  • 300W LED Billboard Light, Adjustable Mounting Bracket Outdoor Sign LED Lighting Fixtures
  • 300W LED Billboard Light, Adjustable Mounting Bracket Outdoor Sign LED Lighting Fixtures
  • 300W LED Billboard Light, Adjustable Mounting Bracket Outdoor Sign LED Lighting Fixtures
  • 300W LED Billboard Light, Adjustable Mounting Bracket Outdoor Sign LED Lighting Fixtures
  • 300W LED Billboard Light, Adjustable Mounting Bracket Outdoor Sign LED Lighting Fixtures
  • 300W LED Billboard Light, Adjustable Mounting Bracket Outdoor Sign LED Lighting Fixtures
300W LED Billboard Light, Adjustable Mounting Bracket Outdoor Sign LED Lighting Fixtures 300W LED Billboard Light, Adjustable Mounting Bracket Outdoor Sign LED Lighting Fixtures 300W LED Billboard Light, Adjustable Mounting Bracket Outdoor Sign LED Lighting Fixtures 300W LED Billboard Light, Adjustable Mounting Bracket Outdoor Sign LED Lighting Fixtures 300W LED Billboard Light, Adjustable Mounting Bracket Outdoor Sign LED Lighting Fixtures 300W LED Billboard Light, Adjustable Mounting Bracket Outdoor Sign LED Lighting Fixtures

300W LED Billboard Light, Adjustable Mounting Bracket Outdoor Sign LED Lighting Fixtures

Wattage             : 300W

IP Rating            : IP66

Input voltage     : 220-240VAC

Light Source       : Lumileds 5050 / Lumileds 3030

Lumens               : 46,500 Lumen (155Lm/W)

Lifespan              : >50,000 hours

CCT                     : 4000K 5000K 5700K

Driver                 : Sosen SS-240GA-56

Equivalent          : 600W HPS / MH

Certification       : CE, RoHS

Inquire Now Next Product

300W LED Billboard Light, Adjustable Mounting Bracket Outdoor Sign LED Lighting Fixtures

Name:

Tel:

E-mail:

Country:

CAPTCHA:

Submit the information to obtain product spec sheet,Please make sure that your email address is absolutely correct!

Specification Sheet
  • Data Sheets
  • Features/Benefits
  • Options/Accessories
  • Package details

300W LED Billboard Light

NEMO series LED billboard lights are the best choice for commercial, industrial sign renovation or new billboards. Perfectly solve the problem of high energy consumption. The 155Lm/W high-efficiency commercial LED billboard light saves more than 75% of electricity consumption. Through our website, you can learn about the purchase of LED billboard lighting and sign fixtures for commercial lighting projects or renovations. In the outdoor advertising industry, lighting is very important in order to make billboards attractive. Ultra-thin, high color rendering and high efficiency are the advantages of our LED lamps, designed to meet the needs of outdoor lighting. The 270° design allows for an optimal illumination angle for uniform illumination during installation. The configuration of the dusk to dawn sensor allows the LED to automatically turn off during the day and automatically turn on at night to achieve perfect lighting while greatly reducing energy consumption.

300w led billboard lighting fixtures


Configure dusk to dawn sensor

With the NEMO series LEDbillboard flood light, because it is equipped with a dusk to dawn photocell sensor, the fixture will automatically turn on at dusk and automatically turn off at dawn, saving energy and labor costs.


led billboard flood light fixtures Configure dusk to dawn sensor300w led billboard flood light fixtures

  • Integrated aluminum material (ADC12) die-casting;

  • The surface is made of black powder sprayed with special metal powder for outdoor use, which increases the frostiness and convexity and expands the heat dissipation area;

  • The chip terminal can be plugged and unplugged between the PCB and the power supply for post-maintenance (replacement of the drive or light source board);

  • Tempered glass adopts snap-on fixing method, which is convenient for post-maintenance (can be opened without tools);

  • The lightweight and ultra-thin design ensures light weight and is easy to transport and install under the premise of ensuring heat dissipation of the lamp;

  • The streamlined appearance has a small drag coefficient, which is also conducive to air flow and heat dissipation Meet ROHS standards;

  • The outer casing is waterproof and integrated, and the waterproof level can reach IP66;

  • The product has passed multiple certifications, ETL CE CB SAA ENEC IP66 IK08 salt spray test


Specifications

ModelLSNFL-300W ( XXK )
Watt300W
Lumen46500 (155Lm/W)
DriverMeanwell
LED BrandLumileds 5050
Input Voltage220-240V
IP & IKIP66 & IK08
Color Temp4000K, 5000K, 5700K
Optional Beam Angle20, 60, 90, 120 degree, 60 degree (p50), 94*47 degree(TypeIV)
Output current2.25A
Number of lamp beads144
Light sourcePhilips 5050philips 3030
Output voltage48V
CertificationsETL, DLC, ENEC, TUV, CE, RoHS, CB, SAA


Size

300w led billboard lighting fixtures size

Installation method

Different installation methods can be selected as needed.

The LED floodlight can be rotated to the optimal illumination angle according to the lighting requirements of the billboard.


300w led billboard lighting fixtures Installation method


Beam angle

The product also has an anti-glare function, which illuminates the billboard like sunlight, so that the billboard can be displayed better. 20, 60, 90, 120 degrees, 60 degrees (p50), 94 * 47 degrees (Type IV).


led billboard lighting fixtures beam angle


Application

The IP66 waterproof and lightweight high-power design makes this LED floodlight ideal for outdoor billboards and sign lighting. Make your ads more attractive.

billboard led lighting fixtures application


LED lighting solution customization

Our engineers can perform professional DIAlux simulations for your billboard LED lighting for free. You only need to provide relevant information, and our engineers will choose the best combination of power and beam angle for you.


billboard led lighting fixtures dialux slimulations

This high quality NEMO LED flood light is designed with the latest technology for optimal performance and is ideal for signs, accent architecture,flags, billboard. LED technology has a longer life expectancy than fluorescent lighting, and emits no UV rays,contains no mercury, and does not flicker.


Anti-glare cover

300w led flood light anti-glare cover accseeory

Optional plug wires and Extended wires

1. Please make sure that all wires are connected correctly when you are installing it.

2.Optional plug wires and Extended wires

300w led billboard sign flood light Optional plug wires and Extended wires

Surge protection device

This fixture is optional with 10KV or 20KV SPD.

SPD surge protection devices is perfectly adapted for outdoor lighting to provide single phase protection for line/neutral, line/ground and neutral/ground in accordance with IEEEE C62.41 2002 C High,UL1449 and IEC61643-11

300w led billboard flood light optional 10kv or 20kv surge protection device

Packaging

300W: 1pc/CNT

carton size: 57*51*13cm GW: 7.0Kg
