60W Round LED High Bay Light,7200 Lumens
  • 60W Round LED High Bay Light,7200 Lumens
  • 60W Round LED High Bay Light,7200 Lumens
  • 60W Round LED High Bay Light,7200 Lumens
  • 60W Round LED High Bay Light,7200 Lumens
  • 60W Round LED High Bay Light,7200 Lumens
60W Round LED High Bay Light,7200 Lumens 60W Round LED High Bay Light,7200 Lumens 60W Round LED High Bay Light,7200 Lumens 60W Round LED High Bay Light,7200 Lumens 60W Round LED High Bay Light,7200 Lumens

60W Round LED High Bay Light,7200 Lumens

1.Wattage: 60W

2.IP Rating: IP65

3.Input voltage: 100-277VAC

4.LED Type: Philips SMD 3030

5.Luminous Flux: 7,200 Lumen

6.Expected Lifespan: >50,000 hours

7.CCT: 3000K/4000K/4500K/5000K/5700K/6500K

8.Power Supply: Meanwell Isolated Power supply(HBG-100-36A)

9.Certficates: ETL DLC TUV CB SAA C-tick LCP RoHS


  • Data Sheets
  • Features/Benefits
  • Options/Accessories
  • Lighing Layout

60W led high bay lighting luminaires

  Using high power Philips SMD 3030 133Lm/W chip,60w led high bay light equivalent to 250W HID/Metal Halide lamp,More beam angle options of reflector lets you choose the right use place.The size of the reflector is optional.25,60,90,100 and 120 degree are available,including 6 items of the aluminum fin reflector,which greatly improves the light utilization.No black spot or blinking.Easy installation, adjustable stand and modules lets you point the light at different angles.Available running at 110VAC & 277VAC,IP65,ideal for indoor and even for outdoor use.Chips are high brightness SMD 3030,Internal waterproof HBG Meanwell Power spply which is listed.

Dimension

60W LED High Bay Light Fixtures size.jpg

Product parameters:

60W LED High Bay Light Fixtures structure.jpg

Main Specification T=25 CelsiusPower SupplyMeanwell Isolated Power supply(HBG-100-36A)
Item No.LSHBL-60WXYPower Efficiency>0.95
LED TypePhilips SMD 3030Replacement250W Metal Halide Lights
Luminous Flux(lm)7200 Lumen


Materials

Extruded aluminum+MPCB+LENS+stainless
CCT(K)3000K/4000K/4500K/5000K/5700K/6500KDimensionDia*H: 345mm*364mm
CRI> 80Base OptionsUS,Europe,UK,Asia standard plug
Beam Angle of reflector25 / 60 / 100 degreeLENsAcrylic LENs
Lifespan (Hrs)> 50,000HoursIP RatingIP65 waterproof and dustproof


Input Voltage(V)

100-277VAC,50/60HzWorking Temp/humidity-25~55 Celsius,10% ~ 90% R.H.
Frenquency (Hz)60/50 HzStorage Humidity-40~85 Celsius,0% ~ 95% R.H.
Power Consumption(W)60WIES files
Lighting simulations support
Power Factor> 0.95CertificateETL DLC TUV CB SAA C-tick LCP RoHS
Time of starting (S)0Environmental certRoHS

Main Feature

60W LED HIGH BAY LIGHT

25,60,90,100 and 120 degree are available

Replacement 250W HiD/Metal Halide

LED High Bay Light Fixtures Main Feature.jpg

Feature

1.The size of the reflector is optional.25,60,90,100 and 120 are available,including 6 items of the aluminum fin reflector,which greatly improves the light utilization.

LED High Bay Light Fixtures reflector size.jpg

2.Five connection ways making the installation easier.Pipe installation,Hook installation,Rings hook installation,E40 base installation,Angle bracket installation,totally are 5 convenient installation ways.

LED High Bay Light Fixtures Connection method.jpg

Test Reports

LED High Bay Light Fixtures Test Reports.jpg

Application

LED high bay light fixtures application.jpg


Feature

1.  60W LED HIGH BAY LIGHT

2.  25,60,90,100 and 120 degree are available

3.  Replacement 250W HiD/Metal Halide

4.  The size of the reflector is optional.25,60,90,100 and 120 are available,including 6 items of the aluminum fin reflector,which greatly improves the light utilization.

5.  Five connection ways making the installation easier.Pipe installation,Hook installation,Rings hook installation,E40 base installation,Angle bracket installation,totally are 5 convenient installation ways.


60W led high bay lights

Package:

1pc per box


Box Size :57*57*26cm   Gross weight: 2.5kg

100° reflectors: 45*45*17cm/8pcs 5.2Kg

60° reflectors: 37*37*20cm /8pcs  4.5Kg

25° reflectors: 44*44*23cm /8pcs  3.5Kg
