110V 220V Linkable LED Flood Light Fixtures, 100W 150W 200W 240W 300W Waterproof Temporary outdoor lighting

18,000-54,000 Lumen (180Lm/W);

Equivalent 200-1000W HPS / MH;

20, 40, 60, 90, 97*47(Type 4), 135*60(P50);

ETL DLC ENEC TUV CB SAA LM79 LM80 IK08 Salt spray Certification;

Linkable Floodlight means that a single generator can be used to light these lights;

Buckle design,tool free open and maintanance;

Lightweight ultra-thin design, light weight, easy to transport and install;

Inquire Now

110V 220V Linkable LED Flood Light Fixtures, 100W 150W 200W 240W 300W Waterproof Temporary outdoor lighting

Name:

Tel:

E-mail:

Country:

CAPTCHA:

Submit the information to obtain product spec sheet,Please make sure that your email address is absolutely correct!

Specification Sheet
  • Data Sheets
  • Beam Angle
  • Options/Accessories
  • Package details

Overview


110V 220V Linkable LED Flood Light Fixtures

Linkable LED Flood Light are all large-scale projects. , Railroad tracks, construction sites, etc. provide high-quality LED temporary lighting to help better complete the work.


Many outdoor projects have a large span. In areas of 500 meters or more, this Linakble LED Flood Light uses only 30% of the power used by fluorescent lights or metal halides, which means it is lighter and more mobile. Good convenience.


Not only that, with a service life of 50,000 hours, higher quality light, and a 5-year warranty, you no longer need to replace the lamps every one or two years. Choosing our Linkable NEMO LED Flood Light is the most economical and effective lighting option for outdoor projects.


110V 220V Linkable LED Flood Light Fixtures

Size

100W-300W Linkable LED Flood Light Fixtures

100W 150W

100W 150W Linkable LED Flood Light Fixtures Dimensions

200W 240W

200W 240W Linkable LED Flood Light Fixtures Dimensions

300W

300W Linkable LED Flood Light Fixtures Dimensions


Specifications

Model

LSNFL-100W(XXK) / LSNFL-150W(XXK) / LSNFL-200W(XXK) / LSNFL-240W(XXK) / LSNFL-300W(XXK)

Watt100W 150W 200W 240W 300W
Lumen18000-54000 Lumens (180Lm/W)
LED BrandLumileds 5050
Input Voltage100-277V
DriverXLG-100-H-A / SS-100GA-56
IP & IKIP66 & IK08
Color Temp3000K, 4000K, 5000K, 5700K, 6000K, 6500K
Optional Beam Angle20, 40, 60, 90, 97*47 degree(Type 4), 135*60 degree(P50);
Output current0.92A
Number of lamp beads72
Light sourcePhilips 5050
Output voltage48V
CertificationsETL DLC ENEC TUV CB SAA LM79 LM80 IK08 Salt spray


Show details

Linkable LED Flood Light Fixtures

1. It can be connected with male and female butt joints, which is more convenient and quick to install;

2.Cable length can be customized according to actual requirements;

3.The end can be covered with waterproof caps instead of using the wiring connector;

4.IP66 Waterproof;




110V 220V Linkable LED Flood Light show

110V 220V Linkable LED Flood Light Show details


Product Features

linkable led flood light structural

1.Ultra high efficiency 180Lm/W LED lights;

2.Can be linked for outdoor temporary work;

3.Lightweight and stackable;

4.Can be wall-mounted, mast-mounted;

5.IP66 waterproof;

6.Optional 3000K-4000k color temperature;

7.ETL DLC ENEC TUV CB SAA LM79 LM80 IK08 Salt spray certification;


Rotatable Bracket

linkable led flood light bracket rotatable

The bracket of this linkable LED Flood Light supports a rotation of 180 degrees, and you can rotate to achieve your satisfactory illumination angle. And the operation is simple, you only need to turn his fixed knob by hand to start adjusting the angle.






led flood light rotatable button


Installation method

Optional Wall installation, Ground installation, Pole installation methods;


linkable led flood light can wall.ground,pole installation


Application

1. Portable floodlighting 2.linkable floodlighting 3.Temporary railway lighting

110V 220V Linkable LED Flood Light application


contact us

Beam angle application

The advantage of Polarized illumination angle is anti-glare, which does not shine on the athlete's eyes when playing, which makes the sports experience and training effect better. Optional 20, 40, 60, 90, 97*47(Type 4), 135*60(P50).

nemo led flood light beam angle

nemo led flood light anti glare beam angle



Accessories

Slip FitterPhotocell sensor1-10V Dimmable
Slip FitterPhotocell sensor1-10V Dimmable
SPD 10KV or 20KVNEMA 3pin PhotocellShorting Cap
SPD 10KV or 20KVNEMA 3pin PhotocellShorting Cap

nemo led flood light with photocell sensor

Anti-glare cover


Optional plug wires and Extended wires

1. Please make sure that all wires are connected correctly when you are installing it.

2.Optional plug wires and Extended wires.

nemo 100w led flood light Optional plug wires and Extended wires

Package details

100W: 1pc/CTN

Carton size: 55*43*17cm GW: 6.5Kg


nemo led flood light packing
