60W 8400lm LED Garden Light Post Top Lantern, Modern Lawn, Pathway Driveway Post Light

●   Watt: 60W

●   Lumens: 7,200/ 8,400

●   Light Source: Lumileds 3030

●   Input Volt: 200-240V

●   IP Rating: IP66 - IK08

●   Arm Dia: 85mm

●   Size: 542x452mm / 21.3x17.8in

●   Lamp Weight: 12.5kg

●   CCT (Color Temp): 3000, 4000, 5000, 5700, 6000

●   Beam Angle: T2/T3/T4 60/90 degree

●   5 years warranty

Inquire Now Next Product

60W 8400lm LED Garden Light Post Top Lantern, Modern Lawn, Pathway Driveway Post Light

Name:

Tel:

E-mail:

Country:

CAPTCHA:

Submit the information to obtain product spec sheet,Please make sure that your email address is absolutely correct!

Specification Sheet
  • Data Sheets
  • Beam Angle
  • Options/Accessories
  • Package details

Specifications

Model

LSPT-60W(XXK)Plus

Watt60W
Lumen7,2008,400
Efficiency

120Lm/W±3%

140Lm/W±3%
Input Volt200-240VAC
Chip BrandLumileds 3030
CCT3000K 4000K 5000K 5700K 6000K
Arm Dia85mm
SPD10KV or 20KV(Optional)
Weight12.5kg
Size

542x452mm / 21.3x17.8in

Beam Angle

T2/T3/T4 60/90 degree

Driver

SS-65GA-56

CertificationETL DLC TUV CE CB SAA RoHS LM79 LM80 TM21 IK10 Salt Spray test approved


Size

60W Plus LED Post Top Light size

Plus LED Post Top Light Fixture lights up


Optional upward or downward light

Optional led garden light glows downwards and upwards


60W Plus LED Post Top Light

Waterproof IP65 - Adopt sealing potting process, better waterproof performance;

Mounting hole - Used for outdoor poles with a diameter of 85mm, with a wide range of applications and easy installation;

Aluminum radiator - The housing uses aluminum radiator and sheet metal frame, and the surface adopts powder spraying process;

High quality LED Chip - Use Lumileds 3030 high quality lamp beads. Light efficiency can reach 140Lm/W;


60W Plus LED Post Top Light

60W Plus LED Post Top Light features

Exploded view of the plus led post top light

Beam Angle

The optical lens is made of PC, and the light transmittance reaches 92%, reducing the loss of light, maximizing the lumen and uniformity of the lighting area and reducing the lighting pollution to nature and human life. Optional 60/90 degree/Type2/Type3/Type4 beam angle.

30W Plus LED Post Top Light beam angle

Installation


60W Plus LED Post Top Light installation


Application

30W Plus LED Post Top Light application

If you want to know more details about the product, or need to provide lighting design for your venue, please feel free to contact us.


contact us


Beam angle

The optical lens is made of PC, and the light transmittance reaches 92%, reducing the loss of light, maximizing the lumen and uniformity of the lighting area and reducing the lighting pollution to nature and human life. Optional 15/25/40/60/90120/30*70/49*21/136*78 degree beam angle.

Plus LED Post Top Light beam angle

Packaging

73*51*29cm 1pc/ctn

GW: 13Kg
