●   Watt: 480W/ 600W

●   Lumens: 81,600/ 96,000

●   Light Source: Lumileds 5050

●   Input Volt: 100-277VAC

●   IP Rating: IP66 - IK10

●   Size: 565*382*155mm

●   Lamp Weight: 10-11kg

●   CCT (Color Temp): 4000, 5000k

●   5 years warranty

●   Beam Angle: 10/20/40/60/140*100/135*60(P50)

Inquire Now Next Product

480W 600W Pole Mount Outdoor 6500k LED Lights | High Efficiency 170Lm/W energy savings LED Lighting

Name:

Tel:

E-mail:

Country:

CAPTCHA:

Submit the information to obtain product spec sheet,Please make sure that your email address is absolutely correct!

Specification Sheet
  • Data Sheets
  • Beam Angle
  • Options/Accessories
  • Package details

Specifications

ModelLSHM‐480W‐LV(XXK)PLUSLSHM‐600W‐LV(XXK)PLUS
Watt480W600W
Lumen81,60096,000
Efficiency170Lm/W±3%160Lm/W±3%
DriverMeanwell 2*ELG-240-48AMeanwell 2*ELGC-300-H-A
Input Volt100-277VAC
Chip BrandLumieleds 5050
CCT4000K, 5000K3000K-6500K
Weight10kg11kg
Size565*382*155mm
IP RatingIP66 & IK10
Wind rating51.0-56.0m/s
CRIRa70 (Ra80, Ra90 optional)
Life TimeL70/B10 >50,000hours
DimmableDimmable and Non-dimmable
Warranty5 Years / 7 years extended warranty available
Beam Angle10 / 20 / 40/ 60 / 90/ 140*100/ 135*60 degree(P50)
CertificationTUV, CE, CB, SAA, RoHS, LM79, LM80, TM21, IK10, Salt Spray test approved


Slim Plus 480 & 600W LED High Pole Light, 170LPW LED Flood High Mast Sports Lighting

Lampshining new 170Lm/W 480/600W outdoor pole LED high mast lighting fixtures replace traditional lighting fixtures and can immediately improve the quality of lighting in stadiums, large areas, roads, ports, and airports, and reduce energy consumption by as much as 75%. And passed the TUV, CE, CB, SAA, RoHS, LM79, LM80, TM21, IK10, Salt Spray test approved.


Slim plus 480w / 600w pole mount led lighting fixtures. 170LM / W is very suitable for central streets, squares, parks, construction sites, docks, airports, Crane LED Lighting. More energy-saving, safe, life span up to 5 years, 100-277vac, very Suitable for replacing 1000W traditional lighting fixtures.


480w 600w pole mount led lighting fixtures


Size

565*382*155mm

480w 600w led high mast light size

Feature

1. High luminaire efficiency up to 170lm/w;

2. Marine grade aluminum housing;

3. IP66 and IK08 protection rate;

4. 5 years warranty;

5. Folding aluminum fin design which are very light weight;

6. TUV, CE, CB, SAA, RoHS, LM79, LM80, TM21, IK10, Salt Spray test approved;


Why Choose 480W/600W Slim Plus LED High Mast Light?

1.High Efficiency

Uses high quality Lumileds 5050, LED High Mast Light Efficiency up to 170Lm/W. Save more energy consumption.

More efficient LED lighting

160-170lpw slim plus 480w 600w led high pole light


2.Heat dissipation

Folding aluminum fin design which are very light weight. Increase the heat dissipation surface area by air cooling to dissipate heat and expand the contact area with air! It speeds up the spread of heat! Thermal effect is good! Compared with traditional die-cast aluminum and profile aluminum, which is heavier and there are certain safety risks. On the contrary ,the aluminum fin heat sink are more secure.


480w 600w led high pole light folding aluminum fin design


3.Dustproof net

protect the lamp from other debris.


480w 600w led high pole light with dustproof net


4.Waterproof IP66

Waterproof IP66, safer for outdoor use.

waterproof ip66 480w 600w led high pole light


5. Higher quality lighting

The lampshining Slim plus series LED high mast light can achieve high-quality lighting, CRI> 80. If there is a higher requirement for lighting, we can customize CRI> 90.

high CRI/TLCI slim plus led high mast light


6.Laser pointer calibration

Laser Tech, help to do final calibration.

It is more convenient to control the illumination direction of the lamp during installation.

Laser pointer

slim plus led high mast light with Laser pointer


Photometrics

The optical lens is made of PC, and the light transmittance reaches 92%, reducing the loss of light, maximizing the lumen and uniformity of the lighting area and reducing the lighting pollution to nature and human life. Optional 10/20/40/60/90 degree / TypeIV / P50 beam angle.

slim plus led high mast light baem angleg


Certification Testing


Installation


Application

slim plus led high mast light application


Click to contact us for more detailed information and the latest quotation!

contact us

Beam angle

The optical lens is made of PC, and the light transmittance reaches 92%, reducing the loss of light, maximizing the lumen and uniformity of the lighting area and reducing the lighting pollution to nature and human life. Optional 10/20/40/60/90 degree / TypeIV / P50 beam angle.

slim plus led high mast light baem angleg

Accessories

10KV or 20KV SPD
1-10V Dimmable
347-480VAC(Sosen driver)
Dali dimmable(Sosen driver)
Anti-glare plate200W 38,000LM LED Flood Light, 1-10V Dimmable Bracket Rotatable Aluminum 7kg Module Area Light
Laser pointer200W 38,000LM LED Flood Light, 1-10V Dimmable Bracket Rotatable Aluminum 7kg Module Area Light


Anti-glare Cover(optional)

anti glare cover accessory

Bending lamp mounted Bracket(optional)

Optional tilt angle bending bracket, more convenient installation

Bending lamp mounted Bracket

Carton

480W/600W: 1pc/ 46*64*22cm

GW: 480W(14Kg), 600W(15Kg)
