600W LED Flood Light 190Lm/W, Aluminum 3 Module 4000K 5000K Easy to assemble Waterproof Outdoor Pole Light

●   Watt: 600W

●   Lumens: 108,000/ 114,000

●   Light Source: Lumileds 5050

●   Input Volt: 100-277VAC

●   IP Rating: IP66 - IK10

●   Size: 565*434*155mm

●   Lamp Weight: 13kg

●   CCT (Color Temp): 4000, 5000k

●   5 years warranty

●   Beam Angle: 10/20/40/60/140*100/135*60(P50)

Inquire Now Next Product

600W LED Flood Light 190Lm/W, Aluminum 3 Module 4000K 5000K Easy to assemble Waterproof Outdoor Pole Light

Name:

Tel:

E-mail:

Country:

CAPTCHA:

Submit the information to obtain product spec sheet,Please make sure that your email address is absolutely correct!

Specification Sheet
  • Data Sheets
  • Beam Angle
  • Options/Accessories
  • Package details

Specifications

ModelLSHM‐600W‐LV(XXK)PLUS
Watt600W
Lumen108,000114,000
Efficiency180Lm/W±3%190Lm/W±3%
DriverMeanwell 3*ELG-240-48A
Input Volt100-277VAC
Chip BrandLumieleds 5050
CCT4000K, 5000K
Weight13.0kg
Size565*434*155mm
IP RatingIP66 & IK10
Wind rating51.0-56.0m/s
CRIRa70 (Ra80, Ra90 optional)
Life TimeL70/B10 >50,000hours
DimmableDimmable and Non-dimmable
Warranty5 Years / 7 years extended warranty available
Beam Angle10 / 20 / 40/ 60 / 90/ 140*100/ 135*60 degree(P50)
CertificationTUV, CE, CB, SAA, RoHS, LM79, LM80, TM21, IK10, Salt Spray test approved


High Efficiency LED Large Area Light 600W 114,000Lm, 5000K Waterproof LED Lighting

Lampshining new 190Lm/W 600W outdoor high power LED Large Area Light fixtures replace traditional lighting fixtures and can immediately improve the quality of lighting in stadiums, large areas, roads, ports, and airports, and reduce energy consumption by as much as 75%. And passed the TUV, CE, CB, SAA, RoHS, LM79, LM80, TM21, IK10, Salt Spray test approved.


Anti-glare will reduce the vertigo effect. This feature is very important for roads or stadiums. Our 600w LED high mast light anti-glare lens can be installed to achieve anti-glare effect without other operations. And the efficiency is as high as 190LM/W. Higher efficiency means that fewer lights can be installed to obtain higher quality lighting , Security is better.


LED Large Area Light 600W

slim plus led high mast light application

slim plus led high mast light application


Size

565*434*155mm

600w slim plus LED Large Area Light size

Feature

1. High luminaire efficiency up to 190lm/w;

2. Marine grade aluminum housing;

3. IP66 and IK08 protection rate;

4. 5 years warranty;

5. Folding aluminum fin design which are very light weight;

6. TUV, CE, CB, SAA, RoHS, LM79, LM80, TM21, IK10, Salt Spray test approved;


Why Choose 720W/900W Slim Plus LED High Mast Light?

1.High Efficiency

Uses high quality Lumileds 5050, LED High Mast Light Efficiency up to 190Lm/W. Save more energy consumption.

slim plus led light high efficiency 180lm/w

600w high efficiency 180-190lm/w LED Large Area Light


2.Waterproof IP66

Waterproof IP66, safer for outdoor use.


600W waterproof ip66 LED Large Area Light


3.Dustproof net

protect the lamp from other debris.


600w LED Large Area Light with dustproof net


4.Heat dissipation

Folding aluminum fin design which are very light weight. Increase the heat dissipation surface area by air cooling to dissipate heat and expand the contact area with air! It speeds up the spread of heat! Thermal effect is good! Compared with traditional die-cast aluminum and profile aluminum, which is heavier and there are certain safety risks. On the contrary ,the aluminum fin heat sink are more secure.


600W folding aluminum fin design LED Large Area Light


5.Laser pointer calibration

Laser Tech, help to do final calibration.

It is more convenient to control the illumination direction of the lamp during installation.

Laser pointer

slim plus LED Large Area Light with Laser pointer


6. Higher quality lighting

The lampshining Slim plus series LED high mast light can achieve high-quality lighting, CRI> 80. If there is a higher requirement for lighting, we can customize CRI> 90.

high CRI/TLCI slim plus LED Large Area Light


Photometrics

The optical lens is made of PC, and the light transmittance reaches 92%, reducing the loss of light, maximizing the lumen and uniformity of the lighting area and reducing the lighting pollution to nature and human life. Optional 10/20/40/60/90 degree / TypeIV / P50 beam angle.

led area light baem angle


Certification Testing


Installation


Application

slim plus led high mast light application


Click to contact us for more detailed information and the latest quotation!


contact us

Beam angle

The optical lens is made of PC, and the light transmittance reaches 92%, reducing the loss of light, maximizing the lumen and uniformity of the lighting area and reducing the lighting pollution to nature and human life. Optional 10/20/40/60/90 degree / TypeIV / P50 beam angle.

led area light baem angle

Accessories

10KV or 20KV SPD
1-10V Dimmable
347-480VAC(Sosen driver)
Dali dimmable(Sosen driver)
Anti-glare plate200W 38,000LM LED Flood Light, 1-10V Dimmable Bracket Rotatable Aluminum 7kg Module Area Light
Laser pointer200W 38,000LM LED Flood Light, 1-10V Dimmable Bracket Rotatable Aluminum 7kg Module Area Light


Anti-glare Cover(optional)

anti glare cover accessory

Bending lamp mounted Bracket(optional)

Optional tilt angle bending bracket, more convenient installation

Bending lamp mounted Bracket

Carton

600W : 1pc/ 51*64*22cm

GW:17.5Kg
