1000W LED Light Super Efficient Energy saving, 180,000Lm Large Area Lighting

●   Watt: 1000W

●   Lumens: 180,000/ 190,000

●   Light Source: Lumileds 5050

●   Input Volt: 100-277VAC

●   IP Rating: IP66 - IK10

●   Size: 565*730*155mm

●   Lamp Weight: 18kg

●   CCT (Color Temp): 4000, 5000k

●   5 years warranty

●   Beam Angle: 10/20/40/60/140*100/135*60(P50)

Inquire Now Next Product

1000W LED Light Super Efficient Energy saving, 180,000Lm Large Area Lighting

Name:

Tel:

E-mail:

Country:

CAPTCHA:

Submit the information to obtain product spec sheet,Please make sure that your email address is absolutely correct!

Specification Sheet
  • Data Sheets
  • Beam Angle
  • Options/Accessories
  • Package details

Specifications

ModelLSHM‐1000W‐LV(XXK)PLUS
Watt1000W
Lumen180,000190,000
Efficiency180Lm/W±3%190Lm/W±3%
DriverMeanwell 5*ELG-240-48A
Input Volt100-277VAC
Chip BrandLumieleds 5050
CCT4000K, 5000K
Weight18kg
Size565*730*155mm
IP RatingIP66 & IK10
Wind rating51.0-56.0m/s
CRIRa70 (Ra80, Ra90 optional)
Life TimeL70/B10 >50,000hours
DimmableDimmable and Non-dimmable
Warranty5 Years / 7 years extended warranty available
Beam Angle10 / 20 / 40/ 60 / 90/ 140*100/ 135*60 degree(P50)
CertificationTUV, CE, CB, SAA, RoHS, LM79, LM80, TM21, IK10, Salt Spray test approved


Super Efficient Energy saving 1000W LED Light, 190,000Lm Large Area Lighting

Lampshining new 190Lm/W 1000W outdoor pole LED large area lighting fixtures replace traditional lighting fixtures and can immediately improve the quality of lighting in stadiums, large areas, roads, ports, and airports, and reduce energy consumption by as much as 75%. And passed the TUV, CE, CB, SAA, RoHS, LM79, LM80, TM21, IK10, Salt Spray test approved.


1000w Large Area Lighting

slim plus led high mast light application

slim plus led high mast light application


Size

565*730*155mm

slim plus 1000w Large Area Lighting size

Feature

1. High luminaire efficiency up to 190lm/w;

2. Marine grade aluminum housing;

3. IP66 and IK08 protection rate;

4. 5 years warranty;

5. Folding aluminum fin design which are very light weight;

6. TUV, CE, CB, SAA, RoHS, LM79, LM80, TM21, IK10, Salt Spray test approved;


Why Choose 1000W Outdoor Slim Plus LED High Mast Flood Light?

1.High Efficiency

Uses high quality Lumileds 5050, LED High Mast Light Efficiency up to 190Lm/W. Save more energy consumption.

slim plus led light high efficiency 180lm/w

1000w 190lm/w Lumens led Large Area Lighting


2.Heat dissipation

Folding aluminum fin design which are very light weight. Increase the heat dissipation surface area by air cooling to dissipate heat and expand the contact area with air! It speeds up the spread of heat! Thermal effect is good! Compared with traditional die-cast aluminum and profile aluminum, which is heavier and there are certain safety risks. On the contrary ,the aluminum fin heat sink are more secure.


folding aluminum fin design 1000w Large Area Lighting


3.Waterproof IP66

Waterproof IP66, safer for outdoor use.

waterproof ip66 1000w Large Area led Lighting


4.Dustproof net

protect the lamp from other debris.


1000w Large Area Lighting with dustproof net


5.Laser pointer calibration

Laser Tech, help to do final calibration.

It is more convenient to control the illumination direction of the lamp during installation.

Laser pointer

slim plus 1000w Large Area Lighting with Laser pointer


6. Higher quality lighting

The lampshining Slim plus series LED high mast light can achieve high-quality lighting, CRI> 80. If there is a higher requirement for lighting, we can customize CRI> 90.

high CRI/TLCI slim plus 1000w Large Area Lighting


Photometrics

The optical lens is made of PC, and the light transmittance reaches 92%, reducing the loss of light, maximizing the lumen and uniformity of the lighting area and reducing the lighting pollution to nature and human life. Optional 10/20/40/60/90 degree / TypeIV / P50 beam angle.

slim plus 1000w Large Area Lighting baem angleg


Certification Testing


Installation


Application

slim plus 1000w Large Area Lighting application


Click to contact us for more detailed information and the latest quotation!


contact us

Beam angle

The optical lens is made of PC, and the light transmittance reaches 92%, reducing the loss of light, maximizing the lumen and uniformity of the lighting area and reducing the lighting pollution to nature and human life. Optional 10/20/40/60/90 degree / TypeIV / P50 beam angle.

slim plus 1000w Large Area Lighting baem angleg

Accessories

10KV or 20KV SPD
1-10V Dimmable
347-480VAC(Sosen driver)
Dali dimmable(Sosen driver)
Anti-glare plate200W 38,000LM LED Flood Light, 1-10V Dimmable Bracket Rotatable Aluminum 7kg Module Area Light
Laser pointer200W 38,000LM LED Flood Light, 1-10V Dimmable Bracket Rotatable Aluminum 7kg Module Area Light


Anti-glare Cover(optional)

anti glare cover accessory

Bending lamp mounted Bracket(optional)

Optional tilt angle bending bracket, more convenient installation

Bending lamp mounted Bracket

Carton

1000W: 1pc/ 81*64*22cm  GW:21Kg
