120W LED Corn Bulbs 15600Lm Equal 450W HID External driver AC 347V~480V

  • 1. Model NO. : LSCB-120WXY-HV

  • 2. Wattage: 120 Watt

  • 3. Input Voltage: 347-480VAC External driver HVG-150-36A

  • 4. Luminous Flux: 15600 Lumen (130Lm/W)

  • 5. Base: E40/E39(mogul) E27/E26(Medium)

  • 6. CCT: 3000K 4000K 5000K 5700K 6500K

  • 7. Milky cover,clear cover and NO cover options.

  • 8. ETL cETL CE RoHS certified.

  • 9. Equal 450W Metal Halide / HPS / HID Lamp.

  • Data Sheets
  • Features/Benefits
  • Options/Accessories
  • Lighing Layout

Feature

  • Using high brightness of original packed Epistar 2835 SMD chip which achieves 130lm/w

  • As the world's first new products ,LED corn bulb could replace the conventional compact CFL light directly .

  • Unique construction design easier for power supply and light source replacement if needed,with full beam angle (360 degrees).

  • Fin aluminum heat dissipation system(PATENT design).The fan of active air exchanging cooling system in order to speed up heat dissipation.

  • No spot, no black area, long life span and less brightness decay

  • Various lamp bases are available , a wide range of applications.(E39/E40 mogul, E26/E27 medium)

  • Wide voltage External driver AC347-480V,High efficiency constant current drives,Efficiency of power supply is more than 90%.

  • No magnetic disturbance influence and CE & RoHS standard compliant.

  • No UV and near-IR radiation in the light beam.

  • ETL cETL CE RoHS certified.

  • 36 months warranty

etl rohs 120w led corn light bulbs show.jpg


Specifications - LED Corn Bulbs

ModelLSCB-40WXY-HVLSCB-50WXY-HVLSCB-60WXY-HVLSCB-70WXY-HVLSCB-100WXY-HVLSCB-120WXY-HV
Wattage40W50W60W70W100W120W
Luminous Flux5200 Lm6250 Lm7700 Lm9100 Lm13000 Lm15600 Lm
Efficacy130Lm/W
Dimensions4.1x9.09 in4.1x9.09 in4.1x10.51 in4.1x11.93 in5.04x11.3 in5.04x12.1 in
Equal150W175W250W275W400W450W
CCT3000K 4000K 5000K 5700K 6500K
Input Voltage347-480VAC External driver
Power Factor>0.8
Cap TypeE40/E39 (mogul) E27/E26(Medium)
CoverMilky cover,clear cover and NO cover options
Light Source2835 Epistar SMD
Beam Angle360 degrees
IP Rating60
CRI>80
Body Temperature<50 Deg C  @Ta=25 Deg C
Ambient temperature-45 to + 50 Deg C
Rated Lifespan50,000+ hours
CertifiedETL cETL CE RoHS Listed

Dimensions

120W led corn light dimensions ce rohs.jpg

Advantages

led corn light Beam Angle 360 degree  led corn light aluminum fin bulit-in heat sink    Customer Review.jpg

Application

Replacement LED

Replacement LED Description.jpg

led corn light bulbs accessories.jpg

 lengthwidthheightGW(kg)
Inner Box (1pc)15cm15cm36cm
Outer Carton (12pcs)64cm49cm40cm14.5


led corn light package dimmable light bulbs.jpg
