50W LED Flat High Bay Light 6000 Lumen Equivalent 125W HID/Metal Halide Light
  • 50W LED Flat High Bay Light 6000 Lumen Equivalent 125W HID/Metal Halide Light
  • 50W LED Flat High Bay Light 6000 Lumen Equivalent 125W HID/Metal Halide Light
50W LED Flat High Bay Light 6000 Lumen Equivalent 125W HID/Metal Halide Light50W LED Flat High Bay Light 6000 Lumen Equivalent 125W HID/Metal Halide Light

50W LED Flat High Bay Light 6000 Lumen Equivalent 125W HID/Metal Halide Light

  • Light Source: Philips 3030

  • Luminous Flux: 6,000 Lumen

  • Rated Wattage: 50 Watt

  • Base Options:US,Europe,UK,Australia plug

  • Input Voltage: 100-277VAC, 180-480VAC

  • Beam Angle: 45 / 90 / 120 / 160 degrees

  • IP Rating: IP65

  • Lifetime: 50,000+ hours

  • 500W HID/Metal Halide Equivalent.

  • Aluminum fin heat sink+stainless steel

  • ETL TUV SAA C-tick LCP RoHS listed

Inquire Now

50W LED Flat High Bay Light 6000 Lumen Equivalent 125W HID/Metal Halide Light

Name:

Tel:

E-mail:

Country:

CAPTCHA:

Submit the information to obtain product spec sheet,Please make sure that your email address is absolutely correct!

Specification Sheet
  • Data Sheets
  • Beam Angle
  • Options/Accessories
  • Package details

Overview


Size

 50w led low bay luminaire size

Specifications

ModelLSLBL-50WXY
Wattage50W
Luminous Flux6000 Lm
Light Source60pcs SMD 3030 Philips
LED QTY60pcs
Driver PowerExternal Meanwell Driver  HLG-60H-36A
DimensionL*W*H:330*102*201mm(11.93'*4.02'*7.91')
Equivalent 100W  to 125W metal halide / HID lamp Equivalent
CCT3000K/4000-4500K/5000-5700K/6000-6500K
Input Voltage100-300VAC,347-480VAC 50/60Hz
Power Factor>0.95
Cap TypeBase Options:US,Europe,UK,Australia plug
optical lens45 degree, 90 degree ,120 degree
ConstructionBase Options:US,Europe,UK,Australia plug
Beam Angle45,  90 and 120 degrees Optional
IP RatingIP65
CRI>80
Efficacy (lm/W)133
Working Tempe / Humidity-45 to + 50 Deg C / @Ta=25 Deg C
Warranty6 year Warranty
Rated Lifespan50,000+ hours
Certified               ETL cETL TUV CE RoHS SAA FCC PLC DLC Ctick certified


Main Feature

  • 3030 SMD LEDS with high efficacy up to 133 Lm/W.

  • With most suitable beam angle 45, 90 and 120 degrees.

  • Integrated dimming by PWM, Resistance or 0-10V standard.

  • Unique appearance with innovative modular fin heatsink design.

  • Resistant to impact and seismic activities.

  • Instant on and off without delay or re-strike.

  • Industrial die cast anodized aluminum fixture housing.

  • Excellent resistance to corrosion, UV degredation and abrasion.

  • Short circuit, over current, over voltage, over temp protection.

  • IP65 rated for indoor or outdoor applications

  • 6 year system warranty

  • Certifications ETL TUV SAA C-tick LCP RoHS listed

  • Single and Double Hang Ring Pendant Mount and Plate Mount for easy installation


Main Construction Features

led low bay lights detailled low bay lights detail 2led low bay lights detail 3


Installation Methods

led low bay luminaire install  led low bay installation


Installation Height

LED Flat High Bay Light Installation height


Applications

  • Warehouse LED Lighting

  • Tunnel LED Lighting

  • High Mast Lighting

  • High-Bay Lighting

  • Factory Lighting

  • Low Bay Lighting

dlc led low bay luminaire

Accessories

LED Flat low High Bay Light Accessories


Single and Double Hang Ring Pendant Mount and Plate Mount

led low bay installation

Accessoriess

LED Flat High Bay Light accessoriess


Packaging

L*W*H35*19*18cm
Gross Weight2.0kg
Package qty1pc/CTN


Outter Carton:


L*W*H35*19*18cm
Gross Weight2.0kg
Package qty1pcs/CTN
