20W Dimmable LED Corn Bulbs 2,500Lm Equal 75W HID

●   Watt: 20W

●   Lumens: 2,500

●   Light Source: 2835 Epistar SMD

●   Input Volt: 100-277VAC

●   Size: 175*72mm

●   Lamp Weight: 0.3kg

●   Base: E40/ E39/ E27/ E26

●   CCT (Color Temp): 3000-6500K

●   5 years warranty

●   Milky cover,clear cover and NO cover options

Inquire Now

20W Dimmable LED Corn Bulbs 2,500Lm Equal 75W HID

Name:

Tel:

E-mail:

Country:

CAPTCHA:

Submit the information to obtain product spec sheet,Please make sure that your email address is absolutely correct!

Specification Sheet
  • Data Sheets
  • Beam Angle
  • Options/Accessories
  • Package details

Specifications

ModelLSCB-20WXY-D
Watt20W
Lumen2,500
Efficiency125Lm/W±3%
Dimmable1-10VDC/ PWM signal/ Resistance
Dimensions

No cover - E40: Dia72*175mm/ E27: Dia72*172mm

With cover - E40: Dia72*183mm/ E27: Dia72*179mm

Weight0.3kg
Driver

FD-36H-38B

Replaces50W HID
CCT3000K 4000K 5000K 5700K 6500K
Input Voltage100-277VAC
Power Factor>0.8
Cap TypeE40/E39 (mogul) E27/E26(Medium)
CoverMilky cover,clear cover and NO cover options
Light Source2835 Epistar SMD
Beam Angle360 degrees
IP Rating60
CRI>80
Body Temperature<50 Deg C  @Ta=25 Deg C
Ambient temperature-45 to + 50 Deg C
Rated Lifespan50,000+ hours
CertifiedETL cETL DLC SAA CE RoHS Listed


Size

new 20w led corn light bulbs size

led corn light ce rohs certification

30w led corn light FREE brand.jpg


Feature

  • Using high brightness of original packed Epistar 2835 SMD chip which achieves 125lm/w

  • As the world's first new products ,LED corn bulb could replace the conventional compact CFL light directly .

  • Unique construction design easier for power supply and light source replacement if needed,with full beam angle (360 degrees).

  • Fin aluminum heat dissipation system(PATENT design).The fan of active air exchanging cooling system in order to speed up heat dissipation.

  • No spot, no black area, long life span and less brightness decay

  • Various lamp bases are available , a wide range of applications.(E39/E40 mogul, E26/E27 medium)

  • Wide voltage AC100-300V,High efficiency constant current drives,Efficiency of power supply is more than 90%.

  • No magnetic disturbance influence and CE & RoHS standard compliant.

  • No UV and near-IR radiation in the light beam.

  • CE RoHS Certificate.

  • 60 months warranty

20w led corn light Introduction.jpg

Advantages

led corn light aluminum fin bulit-in heat sink    Customer Review led corn light bulbs.jpg

Application

led corn light case20w led corn light lighting

Replacement LED

CFL Replacement - Just plug in,run at 100~240VAC

led corn light CFL_ Replacement.jpg

HPS Replacement - Basllast or transformer should be bypassed before installation

led corn light HPS_ Replacement.jpg

Beam angle

led corn bulb Beam Angle 360 degree

 Adaptor Adaptor dimmer

E39 to E26 Adaptor

E40 to E27 Adaptor

E26 to E39 adaptor

E27 to E40 adapto

traditional dimmer can be used(1-10VDC/PWM signal/Resistance)
 lengthwidthheightGW(kg)
Inner Box (1pc)9cm9cm23cm
Outer Carton (50pcs)42cm51cm42cm16.0
