As a trusted Slim LED Flood Light Supplier, Lampshining offers slim LED flood light fixtures in wattages from 10 W up to 400 W, designed for efficient outdoor lighting with minimal profile. Our slim flood lights deliver high performance—up to 170 lm/W efficiency, IP65/IP66 ingress protection, IK08 impact resistance—and are backed by global certifications. These fixtures are ideal for walls, outdoor areas, warehouses, signage, tunnels and more.
Ultra Slim Design: Models as light as 0.47 kg (10 W) in compact size (166×107×32 mm) reduce freight cost and simplify installation.
High Efficiency: Examples: 10 W model delivers ~1,000 lm (≈ 100 lm/W); 100 W model delivers up to ~17,000 lm (≈ 170 lm/W).
Robust Outdoor Durability: All models IP65/IP66 rated (e.g., 300 W/400 W models) and IK08 for impact resistance; built-in die-cast aluminium housing, 270° adjustable bracket for directional flexibility.
Wide Voltage Compatibility: Most models operate AC 100-277 V (and 200-300 V for higher power); suitable for global mains.
5-Year Warranty & Long Lifespan: Many models include 5 years warranty and rated for 50,000+ hours use — substantial saving in maintenance compared to HID lamps.
Slim Flood Light Supplier Advantage: As your factory-direct slim LED flood light supplier, we offer cost-effective OEM/ODM services, fast delivery, and competitive pricing.
Our slim LED flood light fixtures are widely used in:
Outdoor wall-washing and façade lighting
Parking lots, building exteriors and warehouses
Tunnel lighting and underpass installations
Signboards, billboards and large-format advertisements
Gas stations, industrial yards and perimeter lighting
Below is a sample of our slim flood light range:
| Model | Wattage | Lumens | Input Voltage | IP/IK | Beam Angle |
| 10 W | 10 W | ~1,000 lm | AC 100-277 V | IP65 / IK08 | 120° |
| 20 W | 20 W | ~2,600 lm | AC 100-277 V | IP65 / IK08 | 120° |
| 50 W | 50 W | ~6,500 lm | AC 100-277 V | IP65 / IK08 | 120° |
| 100 W | 100 W | ~12,000-17,000 lm | AC 100-277 V | IP65 / IK08 | 120° |
| 300 W | 300 W | ~39,000-45,000 lm | AC 200-300 V | IP66 / IK08 | 30°/60°/90° etc |
| 400 W | 400 W | ~52,000-60,000 lm | AC 200-300 V | IP66 / IK08 | 30°/60°/90° etc |
Determine the target installation height and coverage area: for example, wall installations typically require 3-6 meters, while pole installations require 8-12 meters.
Select the wattage based on coverage requirements: 10-20W is recommended for short-range wall washes or building facades; 100-300W is recommended for parking lots or 3D advertising.
Choose the appropriate beam angle and bracket, such as a 120° beam for wall washes or 30° or 60° beams for long-range focused advertising.
Consider the waterproof and dustproof rating for the installation environment: IP66 is recommended for outdoor use; IP65 is sufficient for ordinary walls.
Q: Can these "slim LED flood lights" replace traditional metal halide lamps?
A: Yes. Our 20 W lamp (≈2,600 lumens) can replace approximately 75 W MH lamps, while our 100 W model can replace approximately 300 W MH lamps, achieving energy savings of up to 70%.
Q: Are they safe for installation in humid or wet environments?
A: Our 300 W and 400 W models are IP66 rated and salt spray tested, making them suitable for coastal or chemical environments.
Q: Do they have dimming or sensing capabilities?
A: Yes, models starting at 300 W support dimming for use with light or microwave sensors.
Q: I'm a wholesale buyer/distributor. What support can you provide?
A: As a supplier of slim LED flood lights, we offer small orders, OEM services, fast shipping, and complete datasheet downloads.
Ready to choose slim energy-efficient lighting solutions for your project?
